- Questions (16)
The vertical distance between holes is approximately 11" The total height of the wall plate is 11.5".
The Yamaha ats-1080 will connect to the MM540. However, ats-1080 has Keyholes for mounting, which is usually for wall mounting. What you would do in this case is get a couple of bolts, nuts and washers. Attach the bolts, nuts and washers to the attachment on the MantelMount. You don't want to make them tight, just want them adjusted enough so that you can sit/slide the soundbar keyhole on the head of the bolt. Once you do this, you will then adjust the nut and make it as tight as possible.
This is basically the same format as mounting it on the wall, but instead you're mounting it to the mount itself. Please let us know if that makes sense.
support and they will give you the low down on your channel speaker! firstname.lastname@example.org
The MM540 can extend/stick out 18.75" at full length (approximately 90 degrees). However, it will only clear a mantel up to a maximum of 16" of depth.
Thank you for your interest in MantelMount. The MM540 can clear a maximum depth of 16". You also want to make sure that the height above your mantel is a minimum of at least the size of your TV and soundbar, plus an added 9".
Don't hesitate to contact us with any further questions
1 - Do I need the Sonos Beam wall mount also? Or does the Mantel Mount include everything I need?
2 - Can the soundbar mount on the Mantel Mount be adjusted so that it does not stick out beyond the small soundbar to the left and right?
The Sonos Beam will require the Sonos Wall Mount Kit. This is because the mounting holes are located on the bottom of your soundbar rather than the back. If you were to attach it to our bracket without the wall mount kit the speaker would point down rather than forward. The wall mount kit is an L bracket that will reverse the mounting holes (key holes typically) to the back of the sound bar
The horizontal brace that the beam would be attaching to is roughly 29" long(, you will need the SBXL universal soundbar adapter (sold direct), if you want to avoid any exposure of the standard attachment
You're definitely going to need to drill through the stone and get to the studs. You will need to purchase longer lag bolts. The lag bolts we provid are M8 x 60mm, so you will likely need 90 - 100mm lag bolt at minimum.
